Unofficial Keyboard Layouts

Discussion in 'General Discussions' started by Saber, Dec 30, 2013.

  1. Saber

    Saber Advanced Member

    Joined:
    Jan 23, 2012
    Messages:
    1,303
    Finalized Pyra keyboard layouts by _wb_, Grench, comradekingu, ible, mrpalmtop, and Tahatch Bearwolf are here. and klapse's mod of _wb_'s is here

    Discussion thread for them is here.

    Last edited by a moderator: Feb 8, 2016
    Tags:
    szr, comradekingu and FBnil like this.
  2. FBnil

    FBnil Ready to Champion the Pyra to the World...

    Joined:
    Dec 14, 2012
    Messages:
    2,671
    Location:
    Yurp
    updated to reflect new edit on first post on 6 jan 2014

    love the slash as a separate key. Tab is also very welcome. I adhere to _wb_'s post: compose mode is better.

    As for the freed up keys, bring paragraph symbol back , and stick the yuan (W), rupee ® and ¤ (O) currency in there... also ruble and peso. My guess is that each country liked their symbol there. I use the euro, and the dollar to program. I have no love for the pound, but english ppl do. Sure, you can meta+equals, then L to get a pound, but a single key is faster. Or maybe math simbols would be übercool... a pi symbol, sigma, what about FN+shift being yet another layout? (ascii art symbols!)

    Also, the audio on the back... I'd put the power charger there (missing?) and the audio back to the front, as the SOC will be about where it is now, because that is the coolest part of the pandora when held with 2 hands, and you need the audio as far as possible from that noise generator (actually, the screen is the noisy one).

    Nothing on the sides, keep it like that, my hands are there.

    tl;dr: headphone jack to front and altGR on R2 for more custom layouts.

    Last edited by a moderator: Jan 6, 2014
  3. Hồng Thất Công

    Hồng Thất Công Đả Cẩu Bổng Pháp

    Joined:
    Dec 19, 2012
    Messages:
    4,378
    Location:
    Cái Bang
    I would like to see L1L2 and R1R2 like Arkasus' mod.

    I would like the audio jack to be in the back.

  4. Natsu

    Natsu Advanced Member

    Joined:
    Dec 22, 2013
    Messages:
    1,250
    Yeah, the front camera takes up screen space.

  5. MrBazil2k

    MrBazil2k Member

    Joined:
    May 4, 2012
    Messages:
    192
    *hushed whisper from aside*

    ssssssssssSSSpeaker(SSSssssssssss) ?

    ^_^

  6. Binky

    Binky Death's Steed Staff Member

    Joined:
    May 28, 2003
    Messages:
    6,908
    Location:
    16A (TO)
    Camera should be at the side, not the top, IMO

  7. Hồng Thất Công

    Hồng Thất Công Đả Cẩu Bổng Pháp

    Joined:
    Dec 19, 2012
    Messages:
    4,378
    Location:
    Cái Bang
    Heh, thread title is about keyboard

  8. Saber

    Saber Advanced Member

    Joined:
    Jan 23, 2012
    Messages:
    1,303
    Thank you all for the constructive comments. The layout can only be improved by our verbalized ideas.

    Shenmue, what was Arkasus's mod for the shoulder buttons?

    Last edited by a moderator: Dec 31, 2013
  9. TrashyMG

    TrashyMG Sarcasm Dispenser Staff Member

    Joined:
    Jan 18, 2010
    Messages:
    10,474
    Last edited by a moderator: Feb 6, 2016
  10. Natsu

    Natsu Advanced Member

    Joined:
    Dec 22, 2013
    Messages:
    1,250
    Yeah, I know, but I couldn't help myself. Looks like you can get a bigger screen in the same space by going towards the edge.

    Seems like a fair setup for the keyboard.

  11. moxie

    moxie The voice of reason, sense and exasperation Staff Member

    Joined:
    Aug 15, 2006
    Messages:
    2,707
    Location:
    South of Sweden
    Um...An ascii-drawn sketch of a screen with camera says about as much about the real actual physical space requirement of the camera hardware as my 5-year olds lego computer says about the pandoras keyboard feel...

    comradekingu likes this.
  12. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    Space on a shoulder button? Doesn't make much sense to me. Shoulder buttons should be for buttons you typically need to hold. Shift, alt, ctrl make a lot of sense. Left mouse click would also make sense.

    ESC does not need a dedicated key, and it is one of the few keys where it is actually a bad idea to have a dedicated key for it because you don't want to press it accidentally.

    Maybe replace ESC by SPACE, and then you can put "/" (and "?" with shift) where space is now.

    FBnil likes this.
  13. Caine

    Caine Hardcore Member

    Joined:
    Jun 5, 2008
    Messages:
    4,081
    Location:
    Netherlands
    Ooh, another keyboard thread. Where is Cosurgi when we need him :)

    Indeed, shoulder buttons should be all modifiers. It would be nice to have an Fn button there as well, but these typically cannot be remapped which would be a problem during gaming.
    L1 = Ctrl Fn-L1 = RCtrl
    R1 = Alt Fn-R1 = RAlt
    L2 = Lmouse Fn-L2 = Rmouse
    R2 = Shift Fn-R2 = CapsLock
    Though if Fn could be made remappable then I would prefer Fn to take the place of L/Rmouse.
    RCtrl and RAlt are useful to have to have more multipliers available. Similarly I would like to have a NumLock which toggles between sending keycodes for 1-0, /, *, -, +, enter, ins and del and their respective keypad versions. This is useful for having more keybinding options in apps. (e.g. Emacs).

    I wonder if our Vim users agree with this :)
    <edit>I'm not sure I like my del button to be directly above the enter.</edit>

    Last edited by a moderator: Dec 31, 2013
  14. slaeshjag

    slaeshjag ¯\_(ツ)_/¯

    Joined:
    Apr 8, 2010
    Messages:
    2,687
    Location:
    ~Stockholm, Sweden
    ^ ctrl-c works just fine too :p

  15. WizardStan

    WizardStan Mega GP Mania

    Joined:
    May 24, 2008
    Messages:
    16,680
    Am Vim user. Can agree with this. Fn-Q is an extremely easy key combination to map into muscle memory, but not something that is likely to ever be pressed accidentally.

    Last edited by a moderator: Dec 31, 2013
    TrashyMG likes this.
  16. Caine

    Caine Hardcore Member

    Joined:
    Jun 5, 2008
    Messages:
    4,081
    Location:
    Netherlands
    What's this? Key combinations? Careful there WizardStan, that's the road to Emacs :p
    I wasn't entirely serious though. I utilize the Emacs implementation of Vim myself (Evil-mode) and use C-[ instead of ESC.

    Why choose when you can have both?

    Back on topic, is the physical layout of the buttons still open for discussion or is it fixed already?

  17. TrashyMG

    TrashyMG Sarcasm Dispenser Staff Member

    Joined:
    Jan 18, 2010
    Messages:
    10,474
    [​IMG]

    Last edited by a moderator: Dec 31, 2013
    lunavorax, ZetaNeta and FBnil like this.
  18. WizardStan

    WizardStan Mega GP Mania

    Joined:
    May 24, 2008
    Messages:
    16,680
    EvilDragon has said absolutely nothing about the keyboard, other than a picture of the pads so we know the physical location of keys. We know nothing about what will be on those keys, except with some vague ideas.

  19. Grench

    Grench Forum Addict!

    Joined:
    Oct 3, 2008
    Messages:
    6,031
    Given that the photo we'd seen was a protoboard to test other hardware, I don't think we should lock into physical button positions quite yet.

    Ditch the camera entirely.  If it's in the lid it's consuming display space.  If it's in the base it's looking up your nose.

    4 rows of keys under the game controls is good.  You have a row of keys OVER the game controls too - which is good, but why do they stop so early?   Bring those out edge to edge.  Then move backspace to the top right key above the game controls and escape to the top left key above the game controls.

    Run 12 keys total over the top edge and you could have a caps-lock style Fn-lock capability to lock them into function keys mapping.

    So - if the backspace is moved out, then you could move the number keys slightly to the right and free up some room near those D pads for my giant thumbs.

    There are large swaths of plastic around those nubs.  Maybe some smaller semi-recessed buttons in those blank spaces to handle system button needs?  (Like backlight up/down, volume up/down, wifi, bluetooth) and entirely free up that top row for function keys?

  20. Natsu

    Natsu Advanced Member

    Joined:
    Dec 22, 2013
    Messages:
    1,250
    Speaking of the wifi button, shouldn't that be done by software only?
