"Beyond the boring clouds, there's the Sun" - Louis XIV's Linux Counsellor.
SOLEIL is a SL4P, Slackware for Pandora, acting as a PXE server, so you can boot x86, 32 or 64 bits computers with it.
You have a bunch of integrated tools to repair, clone, test.
But the main goal is to have a portable workstation. You work on the Pandora everywhere, and when you have access to a x86, you boot it with your Pandora and continue to work on a big screen, accessing all data on your OP account/shared folder.
Also, you can boot a whole network with the OP.
It's part of the setup i created at work, which booted 300 student's PC.
Works well on CC and 1GHz OP, therefore on RB too.
512M ram is recommended if you plan to run, let's say, more than 5 to 10 active computers.
Wiki:
http://pandorawiki.org/Software_projects/OS/SOLEIL
Get SOLEIL here:
http://slackware.openpandora.org/pandora/index.php?dir=SOLEIL%2FSOLEIL-14.0%2Frootfs
Follow the standard SL4P installation procedure:
http://pandorawiki.org/Software_projects/OS/Slackware#Installation
A 16G card or more is needed.
A standard 100Mbps usb-ethernet adapter is needed + a crossover cable. A normal cable may work, depending of your setup.
I know only one usb-ethernet which does 1000 Mbps:
http://www.logitec.co.jp/products/lan/langtju2b/index.php
Didn't test it yet, but it should work, and be used if you want to max out efficiency.
Of course, a 1000 Mbps switch will be best for > 2 workstations.
The Pandora ethernet adapter has the 10.0.0.1 adress.
You have to edit /etc/dhcpd.conf, and replace the 00:00:00:00:00:00 MAC with your main PC one.
This will give the 10.0.0.2 to your machine, and this is the admin IP, the Slackware filesystem will be mounted as read-write.
Other MAC will be considered as read-only clients, and can also boot flawlessly.
Connect all, set up your PC to boot over ethernet.
Boot SL4P, create user, then boot the PC.
It is recommended to boot at least once a main admin PC to automatically run some x86 install scripts.
Actually, these are the current choices, and state:
-Slackware: 32bit bootable, persistent filesystem. Works.
-Slackware: 64bit bootable, persistent filesystem. Works.
-Slackware 32bit and 64bit, installers. Works.
-Dyne:bolic: based on Debian, music-centric distro. Needs 2G ram. Works.
-System rescue cd: Gentoo-based. Tools for repairs. Works. Filesystem download seems erratic, but it's ok.
-Gparted: Debian-based. Tool to format/resize partitions. Works
-Ghost for linux: tool to backup hard drives, partitions and files. Works. Needs a ftp server, trivial to enable.
-Diagnostic tools, different versions of memtest, and a hardware viewer.
-Local boot: boots the local hard drive.
-Readme: anger vs the bad guys.
-Reboot: works.
-Power off: should work on apm-enabled machines.
The image is less than 4G.
My build system is versatile, SOLEIL can be built from a PC (fast) or the Pandora (very slow), and i plan to integrate it into standard SL4P releases, at least as a package.
I have a TODO list and i'll update this front page along each update.
SOLEIL is a SL4P, Slackware for Pandora, acting as a PXE server, so you can boot x86, 32 or 64 bits computers with it.
You have a bunch of integrated tools to repair, clone, test.
But the main goal is to have a portable workstation. You work on the Pandora everywhere, and when you have access to a x86, you boot it with your Pandora and continue to work on a big screen, accessing all data on your OP account/shared folder.
Also, you can boot a whole network with the OP.
It's part of the setup i created at work, which booted 300 student's PC.
Works well on CC and 1GHz OP, therefore on RB too.
512M ram is recommended if you plan to run, let's say, more than 5 to 10 active computers.
Wiki:
http://pandorawiki.org/Software_projects/OS/SOLEIL
Get SOLEIL here:
http://slackware.openpandora.org/pandora/index.php?dir=SOLEIL%2FSOLEIL-14.0%2Frootfs
Follow the standard SL4P installation procedure:
http://pandorawiki.org/Software_projects/OS/Slackware#Installation
A 16G card or more is needed.
A standard 100Mbps usb-ethernet adapter is needed + a crossover cable. A normal cable may work, depending of your setup.
I know only one usb-ethernet which does 1000 Mbps:
http://www.logitec.co.jp/products/lan/langtju2b/index.php
Didn't test it yet, but it should work, and be used if you want to max out efficiency.
Of course, a 1000 Mbps switch will be best for > 2 workstations.
The Pandora ethernet adapter has the 10.0.0.1 adress.
You have to edit /etc/dhcpd.conf, and replace the 00:00:00:00:00:00 MAC with your main PC one.
This will give the 10.0.0.2 to your machine, and this is the admin IP, the Slackware filesystem will be mounted as read-write.
Other MAC will be considered as read-only clients, and can also boot flawlessly.
Connect all, set up your PC to boot over ethernet.
Boot SL4P, create user, then boot the PC.
It is recommended to boot at least once a main admin PC to automatically run some x86 install scripts.
Actually, these are the current choices, and state:
-Slackware: 32bit bootable, persistent filesystem. Works.
-Slackware: 64bit bootable, persistent filesystem. Works.
-Slackware 32bit and 64bit, installers. Works.
-Dyne:bolic: based on Debian, music-centric distro. Needs 2G ram. Works.
-System rescue cd: Gentoo-based. Tools for repairs. Works. Filesystem download seems erratic, but it's ok.
-Gparted: Debian-based. Tool to format/resize partitions. Works
-Ghost for linux: tool to backup hard drives, partitions and files. Works. Needs a ftp server, trivial to enable.
-Diagnostic tools, different versions of memtest, and a hardware viewer.
-Local boot: boots the local hard drive.
-Readme: anger vs the bad guys.
-Reboot: works.
-Power off: should work on apm-enabled machines.
The image is less than 4G.
My build system is versatile, SOLEIL can be built from a PC (fast) or the Pandora (very slow), and i plan to integrate it into standard SL4P releases, at least as a package.
I have a TODO list and i'll update this front page along each update.
