Well, increasing the frequency isn't easy, as we looked into various PWMs and there wasn't a better one... but the LC filter is a possibility. The Display board is a pretty simple two-layer board, adding two components is no big deal.
Can easily be hacked onto existing boards within minutes. I'll check
slaeshjag
¯\_(ツ)_/¯
Imo, the filter should really be on the input side of the backlight step-up regulator, making the PWM signal an analog value. That lets the switch-mode powersupply regulate brightness at hundreds of kHz instead of what, 100 Hz? The regulator driving the backlight supports this mode.
I'd imagine an LC filter capable of filtering at 100-ish Hz and 10's of mA to be quite large, but it's been a while since I last used LC filters, so I might be wrong...
Although, atm, we really don't need more delays ಠ_ಠ
I'd imagine an LC filter capable of filtering at 100-ish Hz and 10's of mA to be quite large, but it's been a while since I last used LC filters, so I might be wrong...
Although, atm, we really don't need more delays ಠ_ಠ
Christoph.Krn
Advanced Member
That'd be great.The Display board is a pretty simple two-layer board, adding two components is no big deal.
Can easily be hacked onto existing boards within minutes. I'll check
Ted
Member
Great to hear this,Well, increasing the frequency isn't easy, as we looked into various PWMs and there wasn't a better one... but the LC filter is a possibility. The Display board is a pretty simple two-layer board, adding two components is no big deal.
Can easily be hacked onto existing boards within minutes. I'll check
OppositeDay
Member
- Joined
- Jul 27, 2017
- Messages
- 36
(Low-frequency) PWM was my main hang-up about the Pyra, great to hear this!Well, increasing the frequency isn't easy, as we looked into various PWMs and there wasn't a better one... but the LC filter is a possibility. The Display board is a pretty simple two-layer board, adding two components is no big deal.
Can easily be hacked onto existing boards within minutes. I'll check
Video 2 is online
See first post.
See first post.
Failbert
Active Member
- Joined
- Apr 18, 2017
- Messages
- 77
- Age
- 33
Oh wow, I might as well start meeting people and having friends, these messaging apps run so fast I am going to become a succesful and respected person so quick I don't know if I will be able to keep up responding to everybody!!!!
Thanks for the vids guys, in the absence of some big text news these can satisfy the thirst very well
Thanks for the vids guys, in the absence of some big text news these can satisfy the thirst very well
Caine
Hardcore Member
Luckily, there is an xkcd for everything.
You're not wrong. Essentially, the coil and capacitor must store enough energy to keep the LED lit during the off cycle. How large these need to be depends on how much power the LED uses, but I'd guess something around 1mH and 100 uF. That could take a few square centimeters of board space.
Changing the power supply to the LED to one that provides better control over voltage and current would be the ideal solution, but it's probably not feasible to redesign that at this point.
Ted
Member
Based on some laptop reviews on notebookcheck.net, very high frequency could also helpful and many devices using this solution.
Sent from my SM-G900F using Tapatalk
How does What'sApp work on there? I thought the developers had a rather aggressive stance towards open source and reverse engineering, and that everything is tied to a smartphone (or SIM)?
Is the Pyra app based on bits of the Android client? or using a smartphone as a proxy?
Is the Pyra app based on bits of the Android client? or using a smartphone as a proxy?
Just a quick update here: A coil and capacitor does NOT work. The reason you use PWMs for LEDs is because LEDs want a stable voltage. Otherwise, you will reduce their lifetime drastically.
However, the PWM can be programmed via software and could even run at 500Hz.
But then the maximum brightness is lower than it could be. Right now, the PWM frequency is setup in the device tree (so it's fixed), but it could be possible to put that in userspace so everyone can setup his favourite PWM frequency for each brightness
Could this be automatically chosen to minimise audible harmonics?
500Hz may be high enough to be invisible, but it's firmly in the audible range, and inductors have a habit of susurating.
You can hear your TV when it runs with 200 or more Hz? :O
