The Future of Pyra's CPU

Discussion in 'General Discussions' started by Rami, May 25, 2017.

  1. Rami

    Rami Still Fresh

    Joined:
    May 8, 2017
    Messages:
    15
    That is both realistic and depressing at the same time.

    Buuuut.... If I realy want to?!

  2. Grench

    Grench Forum Addict!

    Joined:
    Oct 3, 2008
    Messages:
    6,138
    Then keep it in the by then heavily worn Pyra case and buy a fresh one with the new SoC?

    Rami likes this.
  3. trix

    trix Very Active Member

    Joined:
    Jan 11, 2010
    Messages:
    422
    I like this idea. Already when I get a Pyra, my old Pandora will be re-purposed for TV-out or 2-player console emulation (over LAN along with Pyra). If and when a newer CPU board upgrade is released, it would be awesome if the old CPU board could be used to upgrade a TV into a really smart TV (with a full Linux OS on it) and at that point, replace the Pandora if mine is still functional by then.

    At which point the Pandora becomes a hand-me-down to someone who lacks a handheld game system but would very much appreciate one.

    Color me interested.

  4. 2coop4

    2coop4 Still Fresh

    Joined:
    Dec 2, 2016
    Messages:
    26
    I thought Ed said he was gonna release source code so anyone could make new fast cpu or improvements once the pyra was officially released so it wouldn't take so many years to get one


    Sent from my iPod touch using Tapatalk

  5. TrashyMG

    TrashyMG Sarcasm Dispenser Staff Member

    Joined:
    Jan 18, 2010
    Messages:
    10,556
    He already released the electrical schematics, but not sure who would tackle making a new CPU board outside of anyone in this community, it's no easy task for sure...

  6. 2coop4

    2coop4 Still Fresh

    Joined:
    Dec 2, 2016
    Messages:
    26
    Oh I must of missed that post then. There is a lot happening in my life at the moment can't see everything at once


    Sent from my iPod touch using Tapatalk

  7. TrashyMG

    TrashyMG Sarcasm Dispenser Staff Member

    Joined:
    Jan 18, 2010
    Messages:
    10,556
    They will likely be updated again after launch as I'm guessing there may be some minor tweaks in the design from back when these were posted.
    https://pyra-handheld.com/boards/threads/power-memory-and-schematics.78631/

    2coop4 likes this.
  8. rygD

    rygD Nihilistic Mystic

    Joined:
    Feb 28, 2014
    Messages:
    7,360
    Location:
    Everywhere
    I think he had a tablet on his site I was thinking would benefit from that.

    I would personally want a tablet (standard or e-ink display) that resembles a PADD...probably a red one. ;)

    A functional tricorder would be cool, and it could include a camera and be a Pyra accessory. Call it the Pycorder or Pyracorder, I guess, but I know this isn't really a low development cost device like a tablet. Would be fun, though.

    As long as it is kinda cheap, I would probably get something to use with a tv and the unused SoC.

  9. Yogurt

    Yogurt Still Fresh

    Joined:
    Feb 24, 2017
    Messages:
    18
    I'd like to see an 64 bit arm chip at some point. Core count doesn't matter a whole lot to me, but it would be cool to get a more power board that uses less power :) /dreams

    ible likes this.
  10. qunow

    qunow Newbie

    Joined:
    Jun 7, 2017
    Messages:
    2
    Actually, one of the reason why I'm paying attention on this project is because of the CPU it use. The OMAP 5 while being interesting as it is, is also a rather aged product that half decades have been passed since its release. While its actual performance is unclear due to lack of usage on consumer electronic, other cpu with similar architecture are already hard pressed to handle some of the latest mobile app and games. Should also be less powerful than the portable computer released by the certain Chinese company a while ago. It would be nice if the cpu can be upgraded from it now but OMAP 5430/5432 is already last product in the line released by TI and any upgrading would mean switching manufacturer and redoing everything related to it and the extra time and effort and cost....

  11. Grench

    Grench Forum Addict!

    Joined:
    Oct 3, 2008
    Messages:
    6,138
    Actually, that part shouldn't be as big of an issue as you might be thinking. By making the SoC board modular - and that it includes the RAM on the SoC module, THAT part would need to be redesigned to match up to a future SoC. The 'main board' that has the keyboard on one side and the SDXC slots on the other is relatively 'dumb'. It's systems, for the most part, trunk to the connectors for the SoC module. In theory, any future SoC that can handle at least the I/O lines to the 'dumb' mainboard AND fit in the thermal profile of the device could work.

    Designing a new SoC/RAM/eMMC daughter board is NOT insignificant. But - it is one component that should be able to be redesigned while keeping the rest of the hardware 'as is'.

    I could see this evolving into a 'leap frog' effect. The Pyra comes out, gets wide enough adoption to justify it, gets a new SoC board. It will only be able to take advantage of the features already present in the main board. The main board & case can then get an 'upgrade' to fully take advantage of the new SoC's feature set (which may include things that haven't been invented yet). The combination of the two would be a Pyra II? But the point is that by having the system modular, it is hypothetically possible for each piece to receive upgrades independently.

    Where I expressed skepticism above was to the idea of re-using the 'old' Pyra SoC componnent 3-5 years from now in a non-Pyra enclosure after an upgrade SoC has taken it's place in the Pyra. By then, a functioning used Pyra would likely have less value than a dumbed down box would - which would negate the need for a dumbed down box (with it's development costs) to house the module.

    That doesn't preclude the Pyra from having 'sister devices' that use the same modular SoC setup - those could make sense far before the Pyra gets an SoC upgrade part.

  12. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,220
    Location:
    Somewhere off the coast of the EU
    Yes, the next CPU board will probably be from a different manufacturer, but don't underestimate the amount of work done on the parts that won't change - selecting an LCD, touchscreen that doesn't cloud the display, keymat, d-pad, designing the way to squeeze in four shoulder buttons, six main game buttons, the main board. It's only the CPU board and maybe a few drivers in the OS that will need to change - even if we go 64bit, those CPUs still ship with a 32 bit mode which should enable widespread compatibility.

    Edit: Ninjaed by @Grench, with a far longer answer.

  13. qunow

    qunow Newbie

    Joined:
    Jun 7, 2017
    Messages:
    2
    I see, thanks for the explanation!

  14. Grench

    Grench Forum Addict!

    Joined:
    Oct 3, 2008
    Messages:
    6,138
    So I was thinking about this modular approach and component upgrade concept.

    In theory, the only piece of the Pyra that shouldn't need to be 'updated' at any point would be the keymat. Replaced if/when worn out - yes. But...

    SoC can be upgraded.
    Main board can be upgraded - conceptually with new/different ports requiring new lower case plastics.
    Keyboard surround/hinge can be upgraded.
    Screen can be upgraded.

    In theory, though, the keymat and keyboard layout could live forever through any other hardware upgrade cycle. Good thing we spent so much time on it.

  15. Robert Taylor

    Robert Taylor Member

    Joined:
    Jun 7, 2017
    Messages:
    38
    Well, the Pyra has a "pressure, humidity- and gas -sensor.". So, yeah. It kind of already is a tricorder. Also, how very german.

  16. Silent-Hunter

    Silent-Hunter Hardcore Member

    Joined:
    May 29, 2010
    Messages:
    3,053
    "Gas sensor" was a mistranslation, that's the barometer.

  17. Ligachamp

    Ligachamp Member

    Joined:
    Jan 17, 2014
    Messages:
    69
    THAT would be awesome! A Micro Pyra Server :D

  18. Caine

    Caine Hardcore Member

    Joined:
    Jun 5, 2008
    Messages:
    4,081
    Location:
    Netherlands
    We should have put one of those port plates on the back:
    [​IMG]
    A missed opportunity :p

    2coop4, rygD, FBnil and 1 other person like this.
  19. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,220
    Location:
    Somewhere off the coast of the EU
    What, no eSATA?!?

    2coop4, rygD and FBnil like this.
