Pyrainput (FunKeyMonkey plugin + pyrainputctl) design

[ible]

i think it would make sense to fire small scroll events at a low frequency when the nub is less off center, and just fire more frequently if the nub is further off center.



[Letalis Sonus]

Analogue scroll events are actually a thing, think of touchpad scrolling. Touchpads are probably providing absolute instead of relative position information, though.



[levi]

Yes, playing with my trackpad, the two-finger scrolling works as if it's sending a up/down arrow key every centimetre or so I move. Maybe a two zoned approach will be enough for everyone, where it scrollls just one tick if you only move it up to half way, but sends repeated clicks if you move it all of the way, at perhaps some user definable frequency if no happy solution can be found between all the users with their pyras thus far (and willing to contribute to this thread).



[bzar]

Analogue scroll events are actually a thing, think of touchpad scrolling. Touchpads are probably providing absolute instead of relative position information, though.

That's a good point, but they're probably handled separately. For example my laptop's touchpad looks like:

Supported events:
  Event type 0 (EV_SYN)
  Event type 1 (EV_KEY)
    Event code 272 (BTN_LEFT)
    Event code 325 (BTN_TOOL_FINGER)
    Event code 328 (BTN_TOOL_QUINTTAP)
    Event code 330 (BTN_TOUCH)
    Event code 333 (BTN_TOOL_DOUBLETAP)
    Event code 334 (BTN_TOOL_TRIPLETAP)
    Event code 335 (BTN_TOOL_QUADTAP)
  Event type 3 (EV_ABS)
    Event code 0 (ABS_X)
      Value     42
      Min        0
      Max     1162
      Resolution      12
    Event code 1 (ABS_Y)
      Value    634
      Min        0
      Max      634
      Resolution      12
    Event code 47 (ABS_MT_SLOT)
      Value      0
      Min        0
      Max        4
    Event code 53 (ABS_MT_POSITION_X)
      Value      0
      Min        0
      Max     1162
      Resolution      12
    Event code 54 (ABS_MT_POSITION_Y)
      Value      0
      Min        0
      Max      634
      Resolution      12
    Event code 55 (ABS_MT_TOOL_TYPE)
      Value      0
      Min        0
      Max        2
    Event code 57 (ABS_MT_TRACKING_ID)
      Value      0
      Min        0
      Max    65535
  Event type 4 (EV_MSC)
    Event code 5 (MSC_TIMESTAMP)
Properties:
  Property type 0 (INPUT_PROP_POINTER)
  Property type 2 (INPUT_PROP_BUTTONPAD)

There's not specific scroll events, just touch and multitouch locations. The actual scrolling behavior is handled somewhere else.



[bzar]

i think it would make sense to fire small scroll events at a low frequency when the nub is less off center, and just fire more frequently if the nub is further off center.

It would probably need two limit values: when it switches to slow speed and when it changes to fast speed. If these are the same number there's an uncomfortable area where the speed would skip erratically due to the noise in the nubs. The principle is simple, but there's some tuning like this to make it feel nice.



[bzar]

Hm, I may have found useful documentation to fix the scrolling in a more standard way. Let's put a pin on that discussion for now.



[bzar]

Just a note: I implemented variable speed scrolling with configurable sensitivity and high resolution scrolling support over the weekend. Should make its way to your pyras at some point. Have fun



[Bosbeetle]

probably unrelated but still I have some questions. Where can I find the used mapping? And how do I run the pyra input tester.

when i run the input tester I cant seem to get the nice keyboard layout that shows if my keys are working... tried running it from tty or terminal. but probably im doing it wrong. I suspect my upper right shoulder to not work, I think its mapped to alt but it doesnt show up/work. thats why I am curious about the mapping.

that and getting to know my pyra


Thanks!

bzar pointed me to xinput which you can install from the repo, it monitors if your keys give an input.



[EvilDragon]

The input tester accesses the hardware directly and therefore conflicts with funkey monkey.
To use it, you must stop funkey monkey temporarily (systemctl stop pyra-input afair)
