Free Lossless Image Format (FLIF)

Discussion in 'Offtopic Discussions' started by _wb_, Sep 6, 2015.

  1. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    Interesting. Could be an ARM vs x86 related bug...

  2. ptitSeb

    ptitSeb Serial Porter

    Joined:
    Aug 15, 2012
    Messages:
    8,408
    Location:
    France, near Lyon
    Yep, probably.

    I started debugging, and also will try to compare execution with an x64 build for reference.

    For now, the Corruption messages are from the "snap" function.
    In my test iamge (a simple png screenshot), I count number of time "ColorRangeCB::snap" is called, and at occurence #577490, the bucket "b" seems empty, with its min and max to default value:
    Code:
    Breakpoint 1, ColorRangesCB::snap (this=0x232a70, this@entry=0x3b12c0, p=p@entry=2, pp=..., minv=@0xbeffe528: 10000, maxv=@0xbeffe524: -10000, v=@0xbeffe46c: 24) at transform/colorbuckets.hpp:300
    300                 e_printf("Corruption detected in snap (%d)!\n", cnt);
    (gdb) p b
    $1 = (const ColorBucket &) @0x22f878: {snapvalues = {<std::_Vector_base<short, std::allocator<short> >> = {
          _M_impl = {<std::allocator<short>> = {<__gnu_cxx::new_allocator<short>> = {<No data fields>}, <No data fields>}, _M_start = 0x0, _M_finish = 0x0, _M_end_of_storage = 0x0}}, <No data fields>},
      values = {<std::_Vector_base<short, std::allocator<short> >> = {_M_impl = {<std::allocator<short>> = {<__gnu_cxx::new_allocator<short>> = {<No data fields>}, <No data fields>}, _M_start = 0x0,
            _M_finish = 0x0, _M_end_of_storage = 0x0}}, <No data fields>}, min = 10000, max = -10000, discrete = true}

    I'll try to break at the same point (with a static counter) in my reference build to see the status of the "b".
    --- Double Post Merged, Sep 10, 2016, Original Post Date: Sep 10, 2016 ---
    Mmm, execution is very different it seems, even if on the same image :(

    break point at the same loop:
    on PC:
    Code:
    Python Exception <class 'RuntimeError'> Type is not a template.:
    Breakpoint 1, ColorRangesCB::snap (this=0x7a64f0, p=0, pp=..., minv=@0x7fffffffd94c: 0, maxv=@0x7fffffffd948: 47, v=@0x7fffffffd7ec: 11)
        at transform/colorbuckets.hpp:300

    and on Pandora:
    Code:
    Breakpoint 1, ColorRangesCB::snap (this=0x232a70, this@entry=0x3b12c0, p=p@entry=2, pp=..., minv=@0xbeffe528: 14, maxv=@0xbeffe524: 17, v=@0xbeffe46c: 24) at transform/colorbuckets.hpp:297
    297                 printf("STOP!\n");

    I will have to change my approach. I'll start with converting simple small files and activate all the "print" function in the code and compare them...
    --- Double Post Merged, Sep 10, 2016 ---
    Of course, simple file just works... And gives amazingly small files (a 8x8 white box is 17 bytes, and a few colored points it 38 bytes). Large uniform bow also doesn't trigger (I assume this simple case have specifcs encoding path).

    This gradiant (black/white in a 800x600 image) triggers the issue.
    I activated all "print" code in colorbuckets.hpp and launch flif with -v
    On the pandora, I got:
    Code:
    Loading input file: ../bwgradiant800x600.png  Alpha channel not actually used, dropping it.
     (800x600)
    Filled color buckets with 0 discrete colors + 731 continous buckets
    Saving Y Color Bucket:
    Saving I Color Buckets

    Saving Q Color Buckets

    Y buckets:
    C0..244
    I buckets:
    C-1..1 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-2..2 C-1..2 C-2..2 C-2..2 C-2..2 C-1..2 C-2..2 C-2..2 C-2..2 C-2..1 C-2..2 C-2..1 C-1..1 C-1..0
    Q buckets:
      C-1..1 E
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 S0
      C-2..2 C-1..0
      C-2..2 C-1..0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 C-1..0
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 C-1..1
      C-2..2 S0
      C-2..2 S0
      C-2..2 S0
      C-2..2 C-1..1
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 S0
      C-2..2 S0
      C-2..2 S0
      C-2..2 S0
      C-1..2 C-1..0
      C-2..2 S1
      C-2..2 C-1..0
      C-2..2 S0
      C-2..2 C0..1
      C-2..2 S0
      C-2..2 S0
      C-1..2 S0
      C-2..2 C-1..0
      C-1..2 E
      C-2..2 S0
      C-2..2 E
      C-1..2 E
      C0..1 E
    Corruption detected!
    Corruption detected!
    Corruption detected!
    Corruption detected!
    Corruption detected!
    Corruption detected!
    flif: flif-enc.cpp:224: void flif_encode_FLIF2_inner(IO&, Rac&, std::vector<Coder>&, const Images&, const ColorRanges*, int, int, const int*) [with IO = FileIO; Rac = RacOutput24<FileIO>; Coder = FinalPropertySymbolCoder<SimpleBitChance, RacOutput24<FileIO>, 10>; Images = std::vector<Image>]: Assertion `curr <= max' failed.
      Aborted

    I have the same on the PC until the "Corruption detected!". Instead, it just save with this output
    Code:
    94% done [23/23] ENC[2,800x600]  Writing checksum: 4CB1EECA
    Wrote output FLIF file test05.flif, 212307 bytes for 800x600 pixels (3.5385bpp)

    --- Double Post Merged, Sep 10, 2016 ---
    on the Pandora, the first "Corruption detected!" message has this backtrace:
    Code:
    (gdb) bt
    #0  ColorRangesCB::snap (this=0x1ff3d8, this@entry=0x3dc948, p=p@entry=2, pp=..., minv=@0xbeffe528: 10000, maxv=@0xbeffe524: -10000, v=@0xbeffe46c: 0) at transform/colorbuckets.hpp:295
    #1  0x0004e130 in predict_and_calcProps_plane<Plane<short>, Plane<unsigned char>, false, false, 2, ColorRanges> (properties=..., ranges=0x3dc948, ranges@entry=0x1ff3d8, image=..., plane=..., planeY=...,
        z=z@entry=1, r=287, r@entry=333092, c=797, c@entry=2, min=@0xbeffe528: 10000, max=@0xbeffe524: -10000, predictor=0, predictor@entry=-1090525912) at common.hpp:295
    #2  0x00048bac in predict_and_calcProps (properties=..., ranges=0x1ff3d8, ranges@entry=0x11f, image=..., z=1, z@entry=0, p=p@entry=2, r=r@entry=287, c=c@entry=797, min=@0xbeffe528: 10000,
        max=@0xbeffe524: -10000, predictor=0, predictor@entry=1) at common.cpp:148
    #3  0x00051524 in find_best_predictor (images=..., ranges=0x11f, ranges@entry=0x1ff3d8, p=p@entry=2, z=0, z@entry=1) at flif-enc.cpp:163
    #4  0x0006d708 in flif_encode<FileIO> (io=..., images=..., transDesc=..., encoding=<optimized out>, learn_repeats=2, acb=-1, palette_size=512, lookback=1, divisor=30, min_size=50,
        split_threshold=split_threshold@entry=349504, cutoff=cutoff@entry=2, alpha=1, alpha@entry=19, crc_check=<optimized out>, crc_check@entry=-1, loss=19, loss@entry=0, predictor=0xffffffff,
        predictor@entry=0xbeffe944, invisible_predictor=invisible_predictor@entry=2) at flif-enc.cpp:947
    #5  0x00128bb4 in encode_flif (argc=argc@entry=1, argv=0x1, argv@entry=0xbeffeb00, images=..., options=...) at flif.cpp:387
    #6  0x001299c8 in handle_encode (argc=1, argc@entry=2, argv=0xbeffeb00, argv@entry=0xbeffeafc, images=..., options=...) at flif.cpp:395
    #7  0x0012a94c in main (argc=2, argv=0xbeffeafc) at flif.cpp:706



    Attached Files:

    lukey likes this.
  3. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    OK, thanks for narrowing it down. So it's a problem in ColorBuckets. You can disable that transform during encoding with -B, and force it with -A.

  4. ptitSeb

    ptitSeb Serial Porter

    Joined:
    Aug 15, 2012
    Messages:
    8,408
    Location:
    France, near Lyon
    Ah thanlks @_wb_ .
    I tried with -B
    Code:
    /media/sda1/sources/git/FLIF/src$ ./flif -v ../bwgradiant800x600.png ../test05.flif -B
    FLIF (Free Lossless Image Format) 0.2.0rc19 [26 Aug 2016]
    Loading input file: ../bwgradiant800x600.png  Alpha channel not actually used, dropping it.
     (800x600)
    flif: flif-enc.cpp:224: void flif_encode_FLIF2_inner(IO&, Rac&, std::vector<Coder>&, const Images&, const ColorRanges*, int, int, const int*) [with IO = FileIO; Rac = RacOutput24<FileIO>; Coder = FinalPropertySymbolCoder<SimpleBitChance, RacOutput24<FileIO>, 10>; Images = std::vector<Image>]: Assertion `curr <= max' failed.
    Aborted

    But it seems it's solthing else.

  5. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    Commenting out the #define USE_SIMD in config.h seems to solve the problem.

    I wonder if this is a compiler issue or a bug in the flif code.

  6. ptitSeb

    ptitSeb Serial Porter

    Joined:
    Aug 15, 2012
    Messages:
    8,408
    Location:
    France, near Lyon
    @_wb_ : I'll test with commenting USE_SIMD.

    In the mean time, I have tried to spot where behaviour differs between pc and pandora.
    Using max verbose (7 I guess), I found this:
    PC:
    Code:
    seb@mint64-VirtualBox ~/git/FLIF $ src/flif -v -v -v -v -v -v -v /mnt/pandora/media/sda1/sources/git/FLIF/bwgradiant800x600.png test05.flif -B
      ____ _(_)____
     (___ | | | ___)   FLIF (Free Lossless Image Format) 0.2.0rc19 [26 Aug 2016]
      (__ | |_| __)    Copyright (C) 2016 Jon Sneyers and Pieter Wuille
        (_|___|_)      License LGPLv3+: GNU LGPL version 3 or later

    This is free software: you are free to change and redistribute it.
    There is NO WARRANTY, to the extent permitted by law.
    Loading input file: /mnt/pandora/media/sda1/sources/git/FLIF/bwgradiant800x600.png  Encountered unknown PNG text chunk (key: Software), ignoring it.
    Alpha channel not actually used, dropping it.
     (800x600, 3 channels, 8-bit)
    Transforms: YCoCg, Bounds[0:0..244][1:-2..2][2:-2..2]
    Plane 0: 0..244
    Plane 1: -2..2
    Plane 2: -2..2
    Using pixel predictor method: -G???  ->  -G200
    i=2, r=1, fr=0, c=0, curr=69, min=0, max=244
    i=2, r=1, fr=0, c=1, curr=172, min=0, max=244
    Learning a MANIAC tree. Iterating 2 times.
    0% done [1/23] ENC[0,100x75]  i=1, r=1, fr=0, c=0, curr=0, min=0, max=244

    and Pandora:
    Code:
    /media/sda1/sources/git/FLIF/src$ ./flif -v -v -v -v -v -v -v ../bwgradiant800x600.png ../test05.flif -B
      ____ _(_)____
     (___ | | | ___)   FLIF (Free Lossless Image Format) 0.2.0rc19 [26 Aug 2016]
      (__ | |_| __)    Copyright (C) 2016 Jon Sneyers and Pieter Wuille
        (_|___|_)      License LGPLv3+: GNU LGPL version 3 or later

    This is free software: you are free to change and redistribute it.
    There is NO WARRANTY, to the extent permitted by law.
    Loading input file: ../bwgradiant800x600.png  Encountered unknown PNG text chunk (key: Software), ignoring it.
    Alpha channel not actually used, dropping it.
     (800x600, 3 channels, 8-bit)
    Transforms: YCoCg, Bounds[0:0..244][1:-2..2][2:-2..2]
    Plane 0: 0..244
    Plane 1: -2..2
    Plane 2: -2..2
    Using pixel predictor method: -G???  ->  -G000
    i=2, r=1, fr=0, c=0, curr=228, min=0, max=244
    i=2, r=1, fr=0, c=1, curr=170, min=0, max=244
    flif: flif-enc.cpp:225: void flif_encode_FLIF2_inner(IO&, Rac&, std::vector<Coder>&, const Images&, const ColorRanges*, int, int, const int*) [with IO = FileIO; Rac = RacOutput24<FileIO>; Coder = FinalPropertySymbolCoder<SimpleBitChance, RacOutput24<FileIO>, 10>; Images = std::vector<Image>]: Assertion `curr <= max' failed.
    Aborted

    So, it seems the function find_best_predictor used in flif-enc.cpp line 948 gives "2" for plane 0 on the PC and "0" on Pandora. Strange.
    --- Double Post Merged, Sep 10, 2016, Original Post Date: Sep 10, 2016 ---
    And I confirm, no SIMD fixed the Pandora build for me too.
    --- Double Post Merged, Sep 10, 2016 ---
    I still have the bug If I activate SIMD but disable it's use in transform/ycocg.hpp
    Strange, as I thought this was the only place where SIMD is used.
    I will leave SIMD out for now to have a working FLIF in codeblocks...

    FBnil likes this.
  7. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    I think the issue is in image/image.hpp, around line 238, where there is some code to align the pixel data on a 16-byte multiple. This code is probably buggy or something, but the bug was probably not discovered yet because on most platforms, the data is already aligned.
    --- Double Post Merged, Sep 10, 2016, Original Post Date: Sep 10, 2016 ---
    OK. Should be fixed now. What a silly bug :)

    https://github.com/FLIF-hub/FLIF/commit/eb4c294a3e0e25113c978fd6ea5951dd48fc1c8b

    _jr_ and FBnil like this.
  8. ptitSeb

    ptitSeb Serial Porter

    Joined:
    Aug 15, 2012
    Messages:
    8,408
    Location:
    France, near Lyon
    Updating my build... Will test when finished (but it takes several minutes to build).
    --- Double Post Merged, Sep 10, 2016, Original Post Date: Sep 10, 2016 ---
    @_wb_ : yes it works for me too :)

    levi, _jr_ and _wb_ like this.
  9. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,231
    Location:
    Somewhere off the coast of the EU
    FWIW, I just built this at fdf0fc21 (v0.2 + fix #301) on my headless P3 server. Perhaps unsurprisingly, the compilation came with a far few warnings of the style:
    Code:
    maniac/../image/image.hpp: In member function ‘virtual FourColorVals ConstantPlane::get4(uint32_t) const’:
    maniac/../image/image.hpp:373:64: warning: SSE vector return without SSE enabled changes the ABI [-Wpsabi]
         FourColorVals get4(const uint32_t pos) const ATTRIBUTE_HOT {

    I guess that's because my Pentium 3 doesn't have any SSE instructions. But I've done a quick test of encoding and decoding on a couple of the included png files. The smaller tux with a limited palette comes back binary identical, but the photographic 512 line image came back slightly larger. Transferring those to my laptop though, they seem to look pretty similar to each other, if not identical.

    It also seems to run a lot more quickly than old v0.1 did, so that's more good news. Thanks for all your hard work so far!

    comradekingu likes this.
  10. Magic Sam

    Magic Sam Forever Homebrew

    Joined:
    Aug 10, 2007
    Messages:
    2,214
    Location:
    Innsmouth, MA
    Hi all :)

    @_wb_ : how was the ICIP conference in Phoenix ?

    Cheers, Magic Sam

    levi likes this.
  11. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    You can get rid of the SSE stuff by commenting out the #define USE_SIMD line in config.h. That should help to get it compiled on that Pentium 3 :)

    It was quite interesting! I put my paper and slides on the FLIF website, in case you're curious: http://flif.info/publications.html

    levi and _jr_ like this.
  12. Marsu42

    Marsu42 Newbie

    Joined:
    Oct 8, 2016
    Messages:
    1
    I tried 0.2 and it's very good and without patent constraints it actually could go places - esp. considering it doesn't feature a generation loss after "lossy" optimization.

    For widespread use, good metadata handling is paramount - it's supposed to support icc, xmp and exif? For this to happen, the support of the one ring app to rule them all would be very welcome - Phil Harvey's exiftool. Please be a dear and send him some flif samples with the respective metadata and a link to the spec, would you :) ...

    http://u88.n24.queensu.ca/exiftool/forum/index.php/topic,7665.msg38910.html#msg38910
    --- Double Post Merged, Oct 8, 2016, Original Post Date: Oct 8, 2016 ---
    Is metadata supposed to work in flif 0.2 anyway? I've tried and ...

    * xmp: encodes ok, but xmp tag is garbled on decoding back to png
    * exif: encodes ok, but tag is lost on conversion back
    * icc: refuses to encode

    See samples attached.


    Attached Files:

    levi likes this.
  13. _wb_

    _wb_ Microbe Staff Member

    Joined:
    Apr 5, 2012
    Messages:
    5,387
    Location:
    Brussels, Belgium
    About exiftool support: see https://github.com/FLIF-hub/FLIF/issues/307 :) (did one of you guys contact him or is this just a coincidence?)

    The issue with XMP when writing PNG has been fixed meanwhile (see https://github.com/FLIF-hub/FLIF/issues/308).

    There is no official standard for encoding Exif in PNG, so I'm currently not saving Exif in PNG.

    What is the problem with ICC? PNGs with iCCP chunks should work fine as input. Are you getting any error/warning? Try -vvvvvvvv for more verbosity (the more -v's the more verbose)...

    _jr_ likes this.
  14. Silent-Hunter

    Silent-Hunter Hardcore Member

    Joined:
    May 29, 2010
    Messages:
    3,053
    Hey so, is FLIF suitable for general use yet, or is the protocol still changing?

  15. Magic Sam

    Magic Sam Forever Homebrew

    Joined:
    Aug 10, 2007
    Messages:
    2,214
    Location:
    Innsmouth, MA
    Hi all :)

    @Silent-Hunter :
    Source: http://flif.info/

    --- Double Post Merged, Sep 13, 2017, Original Post Date: Sep 13, 2017 ---
    @_wb_ : how is FLIF support in PIV going ? ;) :p

    EDIT: I stumbled upon farbfeld some days ago:

    https://tools.suckless.org/farbfeld/

    Opinions ?

    Cheers, Magic Sam

    ible likes this.
  16. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,231
    Location:
    Somewhere off the coast of the EU
    From what I can tell from the fabfeld site is that it's a simple binary format which you then compress using external binary compressors (like bzip2). That isn't suitable for parsing while it's being downloaded I think, as FLIF is, and in any case doesn't sort the data such that it only fills in the small details last.

    I lost some jpeg data which were stored in a CD-R from about 10 years ago recently. I managed to see what could be pulled off using ffmpeg, and it's just the top half inch or so of most photos. If those files had been in FLIF format, I'd still be able to get reasonable approximations of the entire image, even in the cases where the drive couldn't track the data all the way through.

  17. ible

    ible professional vim user

    Joined:
    Mar 24, 2014
    Messages:
    2,174
    Location:
    Seattle, WA
    farbfeld sucks. FLIF rules :). but still need to understand it somehow...

  18. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,231
    Location:
    Somewhere off the coast of the EU
    Download it and start using it then!

  19. Silent-Hunter

    Silent-Hunter Hardcore Member

    Joined:
    May 29, 2010
    Messages:
    3,053
    I used ImageMagick to convert a JPEG to a FLIF, and it made it 10 megabytes bigger.

  20. levi

    levi Still fresh, damnit!

    Joined:
    Oct 6, 2008
    Messages:
    11,231
    Location:
    Somewhere off the coast of the EU
    Well, the L in FLIF stands for lossless, and even if that's a lossless compression of lossy JPEG artifacts it still takes space. You could try cropping the extra 10 megabytes off the resultant FLIF file to turn it into a lossy file, and see which looks better - the JPEG or your cropped FLIF file.

    I also wasn't aware that imagemagick has been updated to support FLIF. I assume that's the latest version, with the published 0.2 version being almost a year old.

    Reminds me, I really should try out FLIF on my newly inherited dual core x64 machine. It's a little heavy for my little atom netbook, at least when processing big photos.


Share This Page

Loading...
