I will be getting a Caanoo very soon. I need help

[Turdfurgeson82]

It doesn't come with any cables. I've read where you can make a charger cable from a Samsung cable that I read works. I'm not sure if the pinout is the same and cannot find clear info. Like where pin 1 is to start testing the cable. I read somewhere you could put 5v to pin 16 and ground to pin 19. Just not sure where these pins are in the connector



[b_o_b]

Does this help?

Tv Out Selfmade Cable?

Hi everyone, I would like to know if it's possible to make a TV-Out Cable for the Caanoo with the Wiz Usb cable? And if yes, How to?

pyra-handheld.com



[Turdfurgeson82]

Yes I've read that. Just not sure which end of the connector is pin 1 to make sure I have the ground and 5v on the right pins



[hmn]

This is for the Wiz, but it might be helpful:

Wiz charging cable (Samsung E810)

Hi all, I purchased a charging cable advertised as working for the Samsung E810. Should this cable work to charge the Wiz out-of-the-box (i.e. without modification)? Just wanted to check before I go to the effort of taking the cable to pieces and attempting a re-wire! Could also be that the...

pyra-handheld.com

On that cable, the USB 5V is also connected to the VBAT pins.

There are some changes between the Wiz and Caanoo Ext port, but as far as I can tell, they should not affect the charging. However, I have read conflicting reports on here whether the Wiz charging cable works on Caanoo.



[Turdfurgeson82]

Thank you I will check it out



[Git1]

You don't need cables to power a caanoo, you need these:



[Turdfurgeson82]

I dont have paddles either

Post automatically merged: Apr 3, 2024

I dont have paddles either



[elw3]

Maybe wait for the questionsk till it is actually there?



[b_o_b]

Maybe wait for the questions till it is actually there?
